ConFlat (CF) UV Grade Quartz (Fused Silica) Viewport

Can't find your size or material?

Need a higher quantity price?

Let us customize your order.

The ConFlat (CF) UV Grade Quartz (Fused Silica) Viewport is equipped with a ConFlat flange and features a UV grade fused silica viewport. It boasts a zero-length profile and utilizes UV grade fused silica windows, ensuring superior optical properties. With a maximum bakeable temperature of 200°C, it can withstand high-temperature processes. This viewport is fully compatible with ultra-high vacuum (UHV) systems, constructed from non-magnetic materials to minimize interference. Moreover, it offers excellent transmission capabilities for UV wavelengths up to 250nm, making it an ideal choice for various UV applications.

Start Shopping

PERFORMANCE & SPECIFICATIONS

Benefits

Window: UV Grade Fused Silica
TWD < 10λ @ 632nm (peak to valley)
Surface Finish: 50/20 scratch-dig
Leak Rate: < 1 X 10^-9 atm-cc/sec He

Sort By

Grouped product items
PART NUMBER	Flange Size	CF Flange OD (In)	Window Diameter (In)	Material	Ships Within	PRICE	ADD TO CART
CF133-ZLVP-Q-UV-0.63	Flange Size DN16CF CF Flange OD (In) 1.33 Window Diameter (In) 0.63 Material 304SS Ships Within 3-5 Days See more CF133-ZLVP-Q-UV-0.63	DN16CF	1.33	0.63	304SS	3-5 Days	$217.00	Starting at: $217.00	PRICE QTY $217.00
CF275-ZLVP-Q-UV-1.40	Flange Size DN40CF CF Flange OD (In) 2.75 Window Diameter (In) 1.40 Material 304SS Ships Within 3-5 Days See more CF275-ZLVP-Q-UV-1.40	DN40CF	2.75	1.40	304SS	3-5 Days	$238.00	Starting at: $238.00	PRICE QTY $238.00
CF338-ZLVP-Q-UV-1.40	Flange Size DN50CF CF Flange OD (In) 3.38 Window Diameter (In) 1.40 Material 304SS Ships Within 3-5 Days See more CF338-ZLVP-Q-UV-1.40	DN50CF	3.38	1.40	304SS	3-5 Days	$265.00	Starting at: $265.00	PRICE QTY $265.00
CF450-ZLVP-Q-UV-2.69	Flange Size DN63CF CF Flange OD (In) 4.50 Window Diameter (In) 2.69 Material 304SS Ships Within 3-5 Days See more CF450-ZLVP-Q-UV-2.69	DN63CF	4.50	2.69	304SS	3-5 Days	$795.00	Starting at: $795.00	PRICE QTY $795.00
CF600-ZLVP-Q-UV-3.88	Flange Size DN75CF CF Flange OD (In) 6.00 Window Diameter (In) 3.88 Material 304SS Ships Within 3-5 Days See more CF600-ZLVP-Q-UV-3.88	DN75CF	6.00	3.88	304SS	3-5 Days	$945.00	Starting at: $945.00	PRICE QTY $945.00
CF800-ZLVP-Q-UV-5.38	Flange Size DN100CF CF Flange OD (In) 8.00 Window Diameter (In) 5.38 Material 304SS Ships Within 3-5 Days See more CF800-ZLVP-Q-UV-5.38	DN100CF	8.00	5.38	304SS	3-5 Days	$2,385.00	Starting at: $2,385.00	PRICE QTY $2,385.00
