ConFlat (CF) DUV Grade Fused Silica Viewport, Single AR Coating

Skip to the beginning of the images gallery

ConFlat (CF) DUV Grade Fused Silica Viewport, Single AR Coating

Can't find your size or material?

Need a higher quantity price?

Let us customize your order.

The ConFlat (CF) DUV Grade Fused Silica Viewport, featuring a Single AR Coating, is specifically designed for deep ultraviolet (DUV) applications. It incorporates laser-grade fused silica windows with an anti-reflective coating, ensuring exceptional performance. The viewport is capable of withstanding baking temperatures up to 200°C, making it suitable for high-temperature processes. Constructed from non-magnetic materials and boasting a zero-length profile, it is perfect for environments where magnetic interference must be minimized. Additionally, the viewport is fully compatible with ultra-high vacuum (UHV) systems, offering reliable functionality in vacuum setups.

Start Shopping

PERFORMANCE & SPECIFICATIONS

Benefits

Window: UV Grade Fused Silica
TWD < 10λ @ 632nm (peak to valley)
Surface Finish: 50/20 scratch-dig
Leak Rate: < 1 X 10^-9 atm-cc/sec He

Sort By

Grouped product items
PART NUMBER	Flange Size	CF Flange OD (In)	Window Diameter (In)	Material	Ships Within	PRICE	ADD TO CART
CF275-ZLVP-Q-DUV-SAR-1064-1.40	Flange Size DN40CF CF Flange OD (In) 2.75 Window Diameter (In) 1.40 Material 304SS Ships Within 3-5 Days See more CF275-ZLVP-Q-DUV-SAR-1064-1.40	DN40CF	2.75	1.40	304SS	3-5 Days	$845.00	Starting at: $845.00	PRICE QTY $845.00
CF275-ZLVP-Q-DUV-SAR-780-1.40	Flange Size DN40CF CF Flange OD (In) 2.75 Window Diameter (In) 1.40 Material 304SS Ships Within 3-5 Days See more CF275-ZLVP-Q-DUV-SAR-780-1.40	DN40CF	2.75	1.40	304SS	3-5 Days	$845.00	Starting at: $845.00	PRICE QTY $845.00
CF450-ZLVP-Q-DUV-SAR-1064-2.70	Flange Size DN63CF CF Flange OD (In) 4.50 Window Diameter (In) 2.70 Material 304SS Ships Within 3-5 Days See more CF450-ZLVP-Q-DUV-SAR-1064-2.70	DN63CF	4.50	2.70	304SS	3-5 Days	$1,520.00	Starting at: $1,520.00	PRICE QTY $1,520.00
CF450-ZLVP-Q-DUV-SAR-780-2.70	Flange Size DN63CF CF Flange OD (In) 4.50 Window Diameter (In) 2.70 Material 304SS Ships Within 3-5 Days See more CF450-ZLVP-Q-DUV-SAR-780-2.70	DN63CF	4.50	2.70	304SS	3-5 Days	$1,520.00	Starting at: $1,520.00	PRICE QTY $1,520.00
